NVIDIA Quadro P5000 Review | 118 Data compared

The HotHardware review evaluates NVIDIA's Pascal-based workstation graphics cards, highlighting the Quadro P6000 and Quadro P5000 as highly capable behemoths designed for the professional market. Built on the GP102 GPU, the flagship P6000 features a fully-enabled architecture with 3,840 CUDA cores, 24GB of GDDR5X memory, a 384-bit interface, and up to 12 TFLOPs of single-precision performance. The lower-tier P5000 utilizes the GP104 GPU, delivering 2,560 CUDA cores, 16GB of GDDR5X memory, a 256-bit interface, and up to 8.9 TFLOPs of compute power. Both dual-slot cards support advanced Pascal features like Simultaneous Multi-Projection, four simultaneous 4K displays at 60Hz via DisplayPort 1.2, and extensive multi-monitor synchronization capabilities using the Quadro Sync II module.

The NVIDIA Quadro P5000 is a mobile high-end workstation graphics card for notebooks based on a slimmed-down 16 nm Pascal GP104 chip with 2,048 shaders. Tailored for professional applications like CAD, 3D medical visualization, and digital content creation, it stands out by offering certified drivers optimized for extreme stability and performance. It features an impressive 16 GB of GDDR5 video memory on a 256-bit bus, giving it a distinct memory capacity advantage over its consumer counterpart, the GeForce GTX 1070, which is limited to 8 GB. In terms of performance, benchmarks show it is capable of running demanding 2010s games like The Witcher 3 and Ghost Recon Wildlands at around 43 to 53 FPS on ultra settings at 1080p, and near 30 to 36 FPS at 4K resolution. The primary pros of the Quadro P5000 include its massive 16 GB frame buffer for rendering large datasets, certified driver stability for professional software, and a major performance leap over previous-generation Maxwell GPUs like the M5000M. However, its cons include lower memory bandwidth compared to standard consumer variants, a high max power...

In his review for Digital Engineering 24/7, David Cohn evaluates NVIDIA's Pascal-based Quadro professional workstation graphics cards, focusing on the mid-range P2000, high-end P4000, and ultra-high-end P5000. Built on a 16nm FinFET+ manufacturing process, this architecture incorporates more CUDA parallel processing cores and larger framebuffers than the previous Maxwell generation. The review highlights significant generation-over-generation performance leaps verified through SPECviewperf 12 benchmarks. For instance, the entry-mid $499 P2000 upgrades to 1024 CUDA cores and a 5GB framebuffer, while the VR-ready $799 P4000 offers 1792 CUDA cores and 8GB of GDDR5 memory. At the ultra-high-end, the $2,499 P5000 delivers 8.9 TFLOPs of single-precision performance by packing 2560 CUDA cores and 16GB of error-correcting GDDR5X memory. Digital Engineering 24/7 The primary pros noted in the review include unprecedented performance-per-watt efficiency and the fact that each new board equals or exceeds the performance of the next-tier model from the previous generation. Furthermore, the cards are fully certified for engineering software, backed by a three-year warranty, and support advanced display configurations—such as syncing up to four P4000 cards via a Quadro Sync II card...

The NVIDIA Quadro P5000 and GeForce GTX 1080 are both powered by the same Pascal GP104 graphics processor, operating at matching base clocks of 1607MHz and boost clocks of 1733MHz. However, the workstation-oriented P5000 distinguishes itself with double the video memory—boasting 16GB of GDDR5X compared to the consumer card's standard capacity. Structurally, it functions as a highly specialized engineering accelerator that exposes 398 OpenGL extensions, which is seven more than its GeForce counterpart. The primary advantages of the P5000 include full hardware-accelerated viewport performance in professional NURBS and tessellation-heavy CAD software (like SolidWorks, CATIA, and NX), native 10-bit windowed OpenGL output for color-accurate video editing, and support for GPU virtualization features like virtual machine passthrough. Conversely, the card carries steep trade-offs regarding its high cost and structural limitations. A major drawback is its price-to-performance ratio for everyday users, as it costs more than twice as much as a GTX 1080 while offering nearly identical raw processing performance in traditional polygon-focused 3D pipelines like 3ds Max and Maya. Overclocking is completely restricted because the card is locked to a 100% TDP...

The NVIDIA Quadro P5000 is a high-end, dual-slot professional graphics card built on the 16nm Pascal architecture. It features 2560 CUDA cores, 16GB of advanced GDDR5X memory, and a 256-bit memory interface that delivers 288 GB/s of bandwidth. In benchmark tests like ESRI ArcGIS and SPECviewperf 12, the P5000 demonstrated a massive leap in rendering performance and framerates over previous-generation models like the M5000, and a noticeable performance tier above the mid-range P4000. It also introduces support for the Quadro Sync II add-in card, allowing enterprise workstations to efficiently drive up to 32 displays simultaneously. The primary pros of the Quadro P5000 are its generous frame buffer memory capacity, robust parallel processing capabilities, and advanced GPU-accelerated ray tracing tech like NVIDIA Iray. These specifications allow the card to easily handle large datasets in complex, intensive enterprise workflows. On the flip side, the major con is its steep $1,900 price tag, which restricts its appeal strictly to organizations and professionals with demanding, highly specific operational needs. Additionally, testing revealed a minor regression in ESRI drawtime, where the P5000 clocked in slightly...
